PAT is no Magic Trick: How On-Line Sensors Facilitate Help to Ensure “Quality by Design”

On-Line Sensors for PAT PAT is no Magic Trick: How On-Line Sensors Facilitate Help to Ensure “Quality by Design”

20.11.2019Author / Editor: Volker Kupitz* / Dominik Stephan

Keeping up with complexity — Bioprocesses are complex — thus, frequent measurement and data-driven real time process management are needed to keep complexity in check. The demand for a PAT that guarantees GMP and includes quality by design calls for specialised on-line sensor solutions. And recent technological developments are up to the task ...
