Profinet Technology Extending Diagnostics and Commissioning of Profinet Industrial Networks
Softing introduces an enhanced version of the proven Profinet commissioning and diagnostics tool Analyzer IE. The new version is called Analyzer Pro and allows the measurement of passive parameters that give a more detailed insight into the Profinet network.
As an enhanced version of the commissioning and diagnostics tool Analyzer IE, Analyzer Pro includes a Tap (Terminal Access Point) device called ‘profitap’. profitap records network communication such as jitter, load ratio and device update rate. According to the company, these so-called passive parameters cannot be determined via actively communicating to devices. With the help of profitap, all packets traveling to and from the controller are analyzed and network communication is recorded. Eventually, the parameters are integrated in the acceptance report and add an additional layer of information which provides more detailed insights into the Profinet network, adds the firm.
Analyzer Pro is the combination of Softing’s products Th Scope software and Th Link PC. It monitors and diagnoses the health of industrial networks so that field devices continue to communicate with PLCs which would otherwise cause plant downtime or outages, states the company. The generated acceptance reports correspond to the recommendations of the ‘Profinet Commissioning Guideline’ from Profibus & Profinet International (PI). Analyzer Pro is tailored to the needs of maintenance and production operations and requires no IT or network expertise on the part of the user. In addition to the Profinet standard, Ethernet/IP, Modbus TCP and Profibus are also supported.
